6. Performance optimisation

6.1. Pipelined execution

Pipelining is a feature for optimising utilization of a multi-IPU system by parallelizing the execution of model partitions, with each partition operating on a separate mini-batch of data. We refer to these partitions here as pipeline stages.

You can split a model into pipeline stages by annotating operations in the ONNX model using the Builder class. There are two APIs. For instance, to place a specific convolution onto pipeline stage 1:

o = builder.aiOnnx.conv([x, w])
builder.pipelineStage(o, 1)

Or using the context manager:

with builder.pipelineStage(1):
    o = builder.aiOnnx.conv([x, w])

Alternatively, if you have annotated the operations with VirtualGraph attributes, then you can defer annotating pipeline stage attributes to the Session constructor. However, it is recommended that you profile the model to choose a partitioning with the optimal utilization.

You can enable pipelined execution by setting the session option enablePipelining to True. See SessionOptions in the PopART C++ API Reference.

Note that, by default, pipelining a training model with variable tensors stored over different pipeline stages results in ‘stale weights’ (see Zhang et al., arXiv:1912.12675). This can be avoided by enabling gradient accumulation. In this case, the pipeline is flushed before the weight update applies the accumulated gradients.

6.2. Graph replication

PopART has the ability to run multiple copies of your model in parallel on distinct sets of IPUs. This is called graph replication. Informally, replication is a means of parallelising your inference or training workloads.

When training, weight updates are coordinated between replicas to ensure replicas benefit from each other’s weight updates. A reduction is applied on the weight updates across replicas according to the ReductionType specified by the accumulationAndReplicationReductionType session option. The reductions involve some communication between replicas. This communication is managed by PopART.

When you use replication, PopART also manages the splitting and distribution of input data, making sure the data specified in the StepIO is split evenly between replicas. This does mean you need to provide enough input data to satisfy all (local) replicas.

There are two tiers of replication available in PopART, local and global, each of which we will describe below.

Note that replication is not supported on IPU model targets.

6.2.1. Local replication

Local replications are replications managed by a single PopART process. This means local replication is limited to those IPUs that are accessible to the host machine that PopART is running on. To enable local replication, set session option enableReplicatedGraphs to True and set replicatedGraphCount to the number of times you want to replicate your model. For example, to replicate a model twice, pass the following session options to your session:

opts = popart.SessionOptions()
opts.enableReplicatedGraphs = True
opts.replicatedGraphCount = 2

Note that if one replica of your model uses, say, 3 IPUs then with a replicatedGraphCount of 2 you will need 6 IPUs to run both replicas. Also, you will need to provide twice the volume of input data. The data returned for each anchor will include a local replication dimension for all values of AnchorReturnType.

More details on the expected shapes of input and output data (for a given set of session options) can be found in the API documentation of the IStepIO and DataFlow classes, respectively.

6.2.2. Global replication

In addition to local replication, it is possible for multiple PopART processes to work together using global replication. With this option, as the PopART processes may run on separate hosts, you are not limited to using only the IPUs that are available to a single host. It is also possible to combine local and global replication.

To enable global replication, set enableDistributedReplicatedGraphs to True and set globalReplicationFactor to the desired total number of replications (including local replication). Finally, globalReplicaOffset must be set to a different offset for each PopART processes involved, using offsets starting from 0 and incrementing by the local replication factor for each process.

For example, if the local replication factor is 2 and we want to replicate this over four PopART processes then we need to configure a global replication factor of 8. We then expect the globalReplicaOffset in the respective PopART processes to be set to 0, 2, 4 and 6, respectively, going up in increments equivalent to the local replication factor. As an example, the configuration of the PopART session on the second host is shown below:

opts = popart.SessionOptions()
# Local replication settings.
opts.enableReplicatedGraphs = True
opts.replicatedGraphCount = 2
# Global replication settings.
opts.enableDistributedReplicatedGraphs = True
opts.globalReplicationFactor = 8
opts.globalReplicaOffset = 2 # <-- Different offset for each PopART instance

Note that when local and global replication are used in tandem the data provided to each PopART instance (in the IStepIO instance passed to Session::run) should contain only the data required for the local replicas. Moreover, the output anchors will also only contain the output data for the local replicas. Essentially, input and output data shapes are unaffected by global replication settings.

More details on the input and output shapes can be found in the API documentation of the IStepIO and DataFlow classes, respectively.

6.3. Sync configuration

In a multi-IPU system, synchronisation (sync) signals are used to ensure that IPUs are ready to exchange data and that data exchange is complete. These sync signals are also used to synchronise host transfers and access to remote buffers.

Each IPU can be allocated to one or more “sync groups”. At a synchronization point, all the IPUs in a sync group will wait until all the other IPUs in the group are ready.

Sync groups can be used to to allow subsets of IPUs to overlap their operations. For example, one sync group can be performing data transfers to or from the host, while another group is processing a previous batch of data.

You can configure the sync groups using the PopART syncPatterns option when creating a device.

For example, the following code shows how to set the sync configuration to “ping-pong” mode.

sync_pattern = popart.SyncPattern.Full
if args.execution_mode == "PHASED":
    sync_pattern = popart.SyncPattern.ReplicaAndLadder
device = popart.DeviceManager().acquireAvailableDevice(
    request_ipus,
    pattern=sync_pattern)

6.3.1. Sync patterns

There are three sync patterns available. These control how the IPUs are allocated to the two sync groups, GS1 and GS2.

The sync patterns are described with reference to the diagram below, which shows four IPUs: A, B, C and D.

Sync patterns in PopART

Fig. 6.1 Sync patterns

  • Full: All four IPUs are in both sync groups. Any communication between the IPUs or with the host, will require all IPUs to synchronise.

  • SinglePipeline: One sync group contains all four of the IPUs. So any communication using that sync group will synchronise all the IPUs.

    The other sync group is used separately by each IPU. This means that they can each sync with the host independently, without syncing with each other. This allows any IPU to be doing host IO, for example, while others are processing data.

  • ReplicaAndLadder: One sync group contains all the IPUs. The other sync group is used independently by sets of IPUs, for example A+C and B+D. This means that each subset can communicate independently of each other. The two groups of IPUs can then alternate between host I/O and processing.

For more information on how the sync groups are used by the Poplar framework, please refer to the Poplar and PopLibs User Guide.
